Miyano BNE-65MYY

Machine capacity
Max. turning dia. (mm)	160
Distance between Spindle (mm)	740
Max. turning length (mm)	380
Max. bar capacity Ø (mm)	65
Chuck size SP1 (mm)	169 (6″)
Chuck size SP2 (mm)	169 (6″)
Turret no. 1 / HD1
Programmable axis	Z1 / X1 / Y1
Y-axis stroke (mm)	100
No. of tooling stations	12
Rotary tool Power (kW)	4,0
Rotary tool Torque (Nm)	25
Rotary tool Speed (Rpm)	6000
Main spindle SP1
Spindle power (kW)	18,5
Spindle torque (Nm)	159 / 129
Spindle Speed (Rpm)	5000
Back spindle / SP2
Spindle power (kW)	11 / 7,5
Spindle torque (Nm)	40
Spindle Speed (Rpm)	5000
XB- axis (back spindle stroke in mm)	155
Machine Data
CNC Control Unit	Mitsubishi M830W
Floor space (mm)	2.860 x 2.190
Weight (Kg)	8130
